Specification
|
|
|
Air Flow Capacity (CFM) |
0 to 2,400
|
|
Pressure Drop (Inches W.C.) |
0.01 |
|
Housing Material Aluminum |
Stainless Steel |
|
Weight (lbs) |
2.0
|
|
Max Operating Temperature (F) |
160 |
|
Dimensions - Inches (L x W x H) |
5.0 x 3.3 x 2.1 |
|
 |
|
|
Electrical |
|
|
Voltage*; |
24/115/230 VAC |
|
Power Consumption |
6 VA |
|
Current Draw (Amps) |
0.24 / 0.05 / 0.03 |
|
Frequency (Hz) |
50 or 60 |
|
Internal Fuse |
0.5 |
|
Field Electrical Connections** |
Terminal Blocks |
|
Approvals / Listings |
ETL |
|
|
|
*Requires external power supplies to convert to 12VDC
AAS-P2412 - 24VAC Input with 12VDC output
AAS-UP12 - 115-240VAC Input with 12VDC output
AAS-UPW12 - 115VAC Input with 12VDC output wall plug
|
|
**12VDC from power supplies is provided to the AAS-DM
by use of a 2.5mm DC power cord provided by AAS. Other
than the wall plug the other two power supplies have
terminal blocks for field electrical connections.
|
